Media
Our work, straight from site.
40 photos of real rack, fibre, networking and install work by IITECH engineers. No stock photos. Client names, site identifiers and labels are withheld or blurred.
Photo gallery
Data centre rack rowRacking, patching and cable management
Fibre patchingSingle-mode and multimode fibre on top-of-rack switches
Rack cablingServers cabled and dressed down the rack
Vertical cable managementDressed and bundled patching
Console and management portsRouter out-of-band access
Labelled fibre runsEvery lead labelled end to end (labels blurred)
Wall cabinet installPatch panel and switching in a wall-mounted cabinet
Optics prepQSFP transceivers and single-mode leads
Top of rackPDUs and aqua fibre routed overhead
Switch fibre patchingSingle-mode fibre into top-of-rack switches
Structured cablingCopper patching, rack to rack
Comms rack installPatch panels, switching and servers
Active optical cablesAOC leads unpacked and checked before install
Server chassis rackedHardware mounted and ready for cabling (label blurred)
Top-of-rack switchingSwitch install and aqua fibre patching
Console cableSerial console access for switch and router builds
Server hardwareRack servers racked and stacked
Rack buildSwitches installed, fibre routed, label printer on hand
Fibre labellingAqua multimode leads labelled at the switch (labels blurred)
Rack row, overheadCable routing and containment
Labelled A/B powerDual power feeds labelled A1 and B1
Server rack, rearDressed power and network cabling
AOC cable prepActive optical cables checked before install
Office comms rackSwitching, patching and recorder installed
Comms roomSwitching and patching
Fibre trayPatching at the top of a new rack
Hot-swap power and fansRedundant PSUs checked after install
Fibre to the switchSingle-mode leads patched into switch optics
Servers stagedRack servers staged before deployment
ProcurementNetworking hardware delivered to site (labels blurred)
Open rackAqua fibre and PDUs in a new cabinet
Router patchingCopper uplinks patched into a router
Chassis installBlade-style chassis installed below a patch panel
AOC leadAqua active optical cable ready to install
Office network cabinetEquipment install and patching
Server frontRack server installed and powered
Laptop repairMemory and component checks during break/fix
Server rackHigh-density servers in a new cabinet
Hardware break/fixLaptop stripped down for a repair
Office comms roomRack and UPS installed in a small comms room
